Black Lion Audio have been revered as the “king of audio mods” for years, and have modded countless recording interfaces over the years. But since the very beginning, we’ve been asked when we would create our own interface. So, we planned, engineered, and worked — all in secret, for years. It took an impressive amount of design to revolutionize bus-powered, studio-grade interfaces.

Now we are responding with Revolution 2×2: the ultimate in portable recording interfaces. Revolution isn’t another run-of-the-mill interface from big brother — it’s the interface the world has always asked for. Don’t just settle for the cheap and portable. Get an interface that can do more than just sketch out a demo… get one that can actually track a top-level record from start to finish.

Specifications:

• 24bit, 192KHz USB C interface
• Bus Powered
• Macro MMC clocking
• Analog circuit design utilising Nichicon, Vishay and Wima capacitors
• PG-i power filtering technology
• USB Class Compliant
• Revolution Software Suite

Get the latest driver for your Revolution interface, including the new Black Lion Audio Mixer!

Mic Input

• Input Impedance = 3.5k Ω
• Maximum input level @ gain min = +8.615 dBu
• Maximum input level @ gain max = -47.182 dBu
• Frequency Response:  frequency response 20 hz to 20 kHz @gain min (input level -1 dBFS) =  +/-0.035 dB
• Frequency Response:  frequency response 20 hz to 20 kHz @gain max (input level -1 dBFS) =  +/-0.803 dB
• THD + N @ 1 kHz @gain min (bandwidth 20 hz-20 kHz, un-weighted,  (input level -1 dBFS) = 0.00098%
• SNR @ 1 kHz @gain min (bandwidth 20 hz-20 kHz, A-weighted, (input level 0 dBFS ) = 108.838 dB
• Dynamic Range  @gain min(bandwidth 20 hz-20 kHz, A-weighted -level 0 dBFS) = 116dB (pre convertor)
• Dynamic Range  @gain min(bandwidth 20 hz-20 kHz, A-weighted -level 0 dBFS) = 109.197dB
• Crosstalk = -92.157 dB

Line Input

• Input Impedance = 10k Ω
• Maximum Input (maximum input level @ gain min) = +19.82 7Bu
• Maximum input level @ gain max = -35.91 Bu
• Gain Range = 55.7
• Frequency Response =  +/-0.036 dB
• THD + N = 0.00094%
• Dynamic Range = 126 dB (pre convertor)
• Dynamic Range = 109.204 dB
• Crosstalk = -92.229 dB

Line Outputs

• Output Impedance = 47 Ω
• Max Output Level = +12.224 dBu
• Frequency Response =  +/-0.089 dBu
• THD+N = 0.00165%
• Dynamic Range = 106 dB (pre mixer and output control)
• Dynamic Range = 101.457 dB

Instrument Input‍

• Input Impedance = 1 MΩ
• Gain Range = 55.7
• Frequency Response =  +/-0.024 dB
• THD + N = 0.00481%
• Dynamic Range = 103 dB (pre converter)
• Dynamic Range = 102.338 dB
• Crosstalk = -94.338 dB

Headphone Outputs‍

• Output Impedance = 10 Ω
• Maximum Signal Output = 2.252 Vrms
• Frequency Response =  +/-0.114 dB
